Overall Living Sq Ft	3488
Plan Type	House
Plan Sets	CAD File, Eight Sets, Five Sets, One Set , Study Set , Vellums
Foundation Options	Slab
Bedrooms	3
Full Baths	3
Garage Stalls	3
Levels	1
Width Feet	108
Width Inches	0
Depth Feet	60
Depth Inches	0
Ridge Height	31'9
Main Ceiling Height	2142
Wall Construction	2x6
Exterior Finish	Stucco
Floor One Sq Ft	3488
Floor Two Sq Ft	0
Floor Three Sq Ft	0
Bonus Sq Ft	630
Basement Sq Ft	0
Porches Sq Ft	0
Garage Sq Ft	1025
Total Covered Sq Ft	5143
Balcony Sq Ft	0
Main Roof Pitch	10 1:2
Foundation	4522
Master Bedroom Floor	1
Laundry Floor	1
Reverse Options	Mirror, Right-Reading
Additional Sets	1 Additional Set, 2 Additional Sets, 3 Additional Sets, 4 Additional Sets, 5 Additional Sets
Half Baths	1
Materials	Materials List

More Views

House Plan #L500-04
