Overall Living Sq Ft	1517
Plan Type	House
Plan Sets	CAD File, Eight Sets, Five Sets, One Set , Study Set , Vellums
Foundation Options	Slab
Bedrooms	2
Full Baths	2
Garage Stalls	2
Levels	1
Width Feet	92
Width Inches	7
Depth Feet	36
Depth Inches	0
Ridge Height	17'2
Main Ceiling Height	535
Wall Construction	2x6
Exterior Finish	Siding, Brick
Floor One Sq Ft	1517
Floor Two Sq Ft	0
Floor Three Sq Ft	0
Bonus Sq Ft	0
Basement Sq Ft	0
Porches Sq Ft	0
Garage Sq Ft	240
Total Covered Sq Ft	2425
Balcony Sq Ft	0
Main Roof Pitch	8:12
Foundation	4522
Master Bedroom Floor	1
Laundry Floor	1
Reverse Options	Mirror, Right-Reading
Additional Sets	1 Additional Set, 2 Additional Sets, 3 Additional Sets, 4 Additional Sets, 5 Additional Sets
Materials	Materials List

More Views

House Plan #L409-22
