House Plan #AR5281-9950

Name: AR5281-9950 - AmazingPlanscom
SKU: AR5281-9950
Availability: InStock

Email to a Friend Be the first to review this product

Quick Overview

Two Story
Six Bedrooms
Five and a half Bathrooms plus a Cabana Bathroom
Two car Garage
Sprawling Spanish style manor offers an enormous amount
of living space
Perfect design for a narrow lot
Columns and arches provide a majestic appearance
Spacious open design is luxurious inside and out
Covered Entry and Patio with summer kitchen
Impressive two story ceiling in Foyer
Large Kitchen with island eating bar and Cafe opens to
Family Room
Library provides a cozy retreat to entertain special guests
Exclusive Master Suite has enormous Walk-In-Closets sitting area and
regal Master Bath
Unique glass block around the spa tub brightens the interior of the
Master Bath

5281 sq ft

Packages From $1,600.00

See What’s Included ›

Select Package⌄

PDF (Single Build)$1,600.00DIGITAL PDF PACKAGE Recommended

This is the standard electronic plan package for building one home. It includes a complete PDF plan set that can be emailed after purchase and locally printed for your builder, lender, permitting office, or personal planning needs. This option is best when you plan to build the design generally as shown.

CAD Files (Plus PDF, Unlimited Build)$1,950.00DIGITAL CAD + PDF PACKAGE

Choose this option when you expect design changes or want your builder, designer, or draftsperson to work from editable files. The CAD package includes digital drawing files plus a PDF set, along with release language for customizing the plan. CAD files require compatible drafting software and someone experienced with residential plan edits.

Select Foundation⌄

Slab Foundation$0.00

Additional Options⌄

No Options$0.00

No additional upgrade selected.

Right Reading Reverse$250.00

Creates a reversed version of the plan with notes and dimensions adjusted so the drawings remain readable.

Your Total:$0.00

Plan Sets

Foundation Options

Additional Sets

Reverse Options

Clear

Price Match Guarantee View our 110% Price Match Policy

Details

Additional Information

Overall Living Sq Ft

5281

Plan Type

House

Plan Sets

CAD File, PDF File

Foundation Options

Slab

Bedrooms

Full Baths

Garage Stalls

Levels

Width Feet

Width Inches

Depth Feet

126

Depth Inches

Ridge Height

29' 5"

Main Ceiling Height

3728

Wall Construction

CMU

Exterior Finish

Stucco

Floor One Sq Ft

2809

Floor Two Sq Ft

2472

Floor Three Sq Ft

Bonus Sq Ft

Basement Sq Ft

Porches Sq Ft

572

Garage Sq Ft

570

Total Covered Sq Ft

6423

Balcony Sq Ft

Main Roof Pitch

5:12

Foundation

Slab

Master Bedroom Floor

Laundry Floor

Reverse Options

Right-Reading

Additional Sets

1 Additional Set, 2 Additional Sets, 3 Additional Sets, 4 Additional Sets, 5 Additional Sets

Half Baths
