House Plan #AR5030-9945

Name: AR5030-9945 - AmazingPlanscom
SKU: AR5030-9945
Availability: InStock

Email to a Friend Be the first to review this product

Price range: $1,900.00 through $2,450.00

Quick Overview

Two Story
Five Bedrooms plus a Maid’s Room
Four Bathrooms plus Cabana Bathroom
Three car Garage
Spacious Covered Entrance
Covered Patio with summer kitchen
Classic Mediterranean style
Towering Covered Entrance with covered balcony
Luxurious inside and out
Formal Dining Room
First Floor VIP Suite with private entrance
Cozy Den / Library makes a perfect place for a quiet retreat
Eight foot French doors with sidelights
Columns arches and baluster rail provide strong curb appeal
Chef’s Dream island Kitchen with eating bar Butler’s Pantry
and cafe opens to the Family Room
Luxurious Master Suite with large Walk-In-Closets tray ceilings
with regal Master Bath with vanity and vanity area opens to private
balcony
Large Living Room features 2 story ceiling a wet bar and fireplace

5030 sq ft

Packages From $1,600.00

See What’s Included ›

PDF (Single Build)$1,600.00DIGITAL PDF PACKAGE Recommended

This is the standard electronic plan package for building one home. It includes a complete PDF plan set that can be emailed after purchase and locally printed for your builder, lender, permitting office, or personal planning needs. This option is best when you plan to build the design generally as shown.

CAD Files (Plus PDF, Unlimited Build)$1,950.00DIGITAL CAD + PDF PACKAGE

Choose this option when you expect design changes or want your builder, designer, or draftsperson to work from editable files. The CAD package includes digital drawing files plus a PDF set, along with release language for customizing the plan. CAD files require compatible drafting software and someone experienced with residential plan edits.

Slab Foundation$0.00

Right Reading Reverse$250.00

Creates a reversed version of the plan with notes and dimensions adjusted so the drawings remain readable.

Plan Sets

Foundation Options

Additional Sets

Reverse Options

Clear

Low Price Guarantee Find a lower price and we’ll beat it by 10%. See Details

Details

Additional Information

Overall Living Sq Ft

5030

Plan Type

House

Plan Sets

CAD File, PDF File

Foundation Options

Slab

Bedrooms

Full Baths

Garage Stalls

Levels

Width Feet

Width Inches

Depth Feet

Depth Inches

Ridge Height

34' 8"

Main Ceiling Height

3728

Wall Construction

CMU

Exterior Finish

Stucco

Floor One Sq Ft

2734

Floor Two Sq Ft

2296

Floor Three Sq Ft

Bonus Sq Ft

Basement Sq Ft

Porches Sq Ft

689

Garage Sq Ft

671

Total Covered Sq Ft

6390

Balcony Sq Ft

432

Main Roof Pitch

5:12

Foundation

Slab

Master Bedroom Floor

202

Laundry Floor

195

Reverse Options

Right-Reading

Additional Sets

1 Additional Set, 2 Additional Sets, 3 Additional Sets, 4 Additional Sets, 5 Additional Sets
