House Plan #AR4087-2017

Name: AR4087-2017 - AmazingPlanscom
SKU: AR4087-2017
Availability: InStock

Email to a Friend Be the first to review this product

Quick Overview

One Story
Five Bedrooms
Three car Garage
Five and a half Bathrooms plus a Cabana Bathroom
Traditional Mediterranean Style
Columns and arches provide strong curb appeal
This design has a features an alternate elevations
Custom Front doors with arched transom accent the covered entrance
Grand covered entrance
Gourmet’s Kitchen with eating bar and pantry
The exclusive Master Suite features his & her walk-in-closets
stylish tray ceilings a luxurious Master Bath and opens to covered patio
The Den offers a more private area for entertaining close friends or
just relaxing
You’ll love this design if you’re looking for a home with a spacious feel
while providing more private places
Large Living Room with high ceilings opens to a large covered patio
Family Room Café and Living room combination are perfect for
entertaining

4087 sq ft

Packages From $1,400.00

See What’s Included ›

Select Package⌄

PDF (Single Build)$1,400.00DIGITAL PDF PACKAGE Recommended

This is the standard electronic plan package for building one home. It includes a complete PDF plan set that can be emailed after purchase and locally printed for your builder, lender, permitting office, or personal planning needs. This option is best when you plan to build the design generally as shown.

CAD Files (Plus PDF, Unlimited Build)$1,750.00DIGITAL CAD + PDF PACKAGE

Choose this option when you expect design changes or want your builder, designer, or draftsperson to work from editable files. The CAD package includes digital drawing files plus a PDF set, along with release language for customizing the plan. CAD files require compatible drafting software and someone experienced with residential plan edits.

Select Foundation⌄

Slab Foundation$0.00

Additional Options⌄

No Options$0.00

No additional upgrade selected.

Right Reading Reverse$250.00

Creates a reversed version of the plan with notes and dimensions adjusted so the drawings remain readable.

Your Total:$0.00
